In stock
Order now and will be shipped in 1 working day.
We can install all products in our workshop. Universal AHD / CVBS Parking Camera – Night Vision, IP68
This universal high-definition parking camera is designed for aftermarket installations where reliability, image quality, and night visibility are critical. Equipped with a 1/2.7” FH8536H + C2399 image sensor, the camera supports CVBS and AHD video formats, making it compatible with a wide range of Android head units, CarPlay screens, and multimedia interface modules.
The camera delivers up to AHD 1080P (1920×1080) resolution with 1000–2000 TVL, providing a sharp and stable image both day and night. Integrated high-brightness IR LEDs ensure excellent visibility in complete darkness, with a night vision range of up to 30 ft (≈9 m).
With IP68 waterproof protection, wide operating temperature range, and a durable flame-retardant PC housing, this camera is suitable for long-term outdoor automotive use. Multiple configuration options such as mirror/non-mirror, guide lines ON/OFF, and image flip allow easy adaptation for rear or front camera applications.
⚠️ Important:
This camera cannot be connected directly to an original factory infotainment system. It requires a device with an RCA video input, such as:
-
CarPlay / Android Auto retrofit module
-
Android multimedia head unit
-
Aftermarket CarPlay screen
Key Features
-
Supports AHD 1080P / AHD 720P / CVBS
-
High-quality 1/2.7” image sensor
-
IR LED night vision, 0 Lux operation
-
IP68 waterproof & dustproof
-
Mirror / Non-Mirror selectable
-
Parking guide lines ON / OFF
-
Image flip supported
-
Wide voltage range 6V–18V (12V standard)
-
Automotive-grade temperature resistance
Technical Specifications
-
Sensor: 1/2.7 FH8536H + C2399
-
Resolution:
-
CVBS: 1920 × 530
-
AHD-720P: 1280 × 720
-
AHD-1080P: 1920 × 1080
-
-
TV Lines: 1000–2000 TVL
-
Video System: NTSC / PAL
-
Video Output: CVBS / AHD
-
Minimum Illumination: 0 Lux (IR LED ON)
-
Night Vision Distance: up to 30 ft
-
Power Consumption: 150 mA
-
Power Supply: 12V (6V–18V supported)
-
Connector: 4-Pin Aviation Female (optional RCA / BMW connector)
-
Waterproof Rating: IP68
-
Material: Flame-retardant PC plastic
-
Operating Temp: -30°C to +75°C
-
Storage Temp: -40°C to +85°C
-
Certification: CE
