Mercedes-Benz Sprinter W906 Rear View Camera – Brake Light Mounted (2006–2019)

Upgrade your Mercedes-Benz Sprinter W906 (2006–2019) with a discreet roof-mounted rear view camera integrated into the brake light, designed to significantly improve parking safety, reversing visibility, and night-time maneuvering.

This camera replaces the factory brake light housing, delivering a factory-style appearance with no external modifications. It provides a wide, clear rear view and is ideal for vans, campers, and commercial vehicles where rear visibility is limited.

Key Features

• OEM-style brake light integration – clean and original look

• High-resolution image (up to AHD 1080P)

• Excellent night vision with high-brightness IR LEDs

• Wide viewing angle for safer reversing and parking

• IP68 waterproof – reliable in all weather conditions

• Supports mirror / non-mirror image & parking guidelines

• Stable operation in extreme temperatures

⚠️ Important compatibility note:
This camera cannot be connected directly to the original Mercedes factory head unit.
It requires a device with RCA video input, such as:

• CarPlay / Android Auto retrofit interface

• Android multimedia head unit

• Aftermarket monitor or display

Parking Camera Specifications

• Sensor: 1/2.7 FH8536H + C2399

• Effective Pixels:

  • CVBS: 1920(H) × 530(V)

  • AHD-720P: 1280(H) × 720(V)

  • AHD-1080P: 1920(H) × 1080(V)

• Resolution: 1000–2000 TVL

• Video System: NTSC / PAL

• Video Signal: CVBS / AHD

• Viewing Angle: Customizable

• Functions:

  • Mirror / Non-Mirror

  • Guide Lines ON / OFF

  • Flip / No Flip

• Minimum Illumination: 0 Lux (LED ON)

• IR LEDs: High-brightness

• Night Vision Distance: up to 30 ft (≈9 m)

• Waterproof Rating: IP68

• Power Consumption: 150 mA

• Power Supply: 12V standard (compatible with 6V–18V)

• Connector:

  • 4-Pin Aviation Female

  • Optional AV + DC or BMW connector

• Operating Temperature: -30°C to +75°C

• Storage Temperature: -40°C to +85°C

• Material: High-temperature resistant PC plastic, flame-retardant

• Certification: CE marked

Vehicle Compatibility

• Mercedes-Benz Sprinter W906

• Model years: 2006–2019
